IPB-5000B
10. External Communication Function
10-16
8) Setting of Initial Setting Condition (P)
Specified
Code
Item Contents
P01 Schedule Select Method
00: Closed Circuit of Schedule Select
Terminal (No Parity)
01: Closed Circuit of Schedule Select
Terminal (Parity Valid)
02: Select on Front Panel
P02
Start Signal Stabilizing
Time (Delay Time)
00: 1ms 01: 5ms
02: 10ms 03: 20ms
P03 End Signal Output Time
00: 10ms 01: 100ms
02: While Start Signal Output
P04
Self-sustaining Time at
Starting
00: No Self-sustaining
01: Self-sustaining from Weld Time
02: Self-sustaining from Squeeze
Time
P10 Weld ON/OFF
00: Weld OFF
01: Weld ON
P40 Weld Transformer
00: IT*-142*6 (Do not select)
01: IT*-360*6 02: IT*-780*6
P41
Monitor Value Display
Mode
00: Slope Time Excluded
01: Slope Time Includes
P43 Transformer Scan Mode
00: OFF 01: ON 02: 1-2
03: 1-3 04: 1-4 05: 1-5
P45
No-current Monitor
Start Time
00 to 10 (Dimension “ms” Eliminated)
P46
Pulse Width Monitor
Start Time
00 to 10 (Dimension “ms” Eliminated)
P47
NG Terminal Mode
Setting
00: Open Circuit at NG
01: Closed Circuit at NG
P48
READY Output Mode
Setting
00: ON at Weld ON
01: ON at Power ON
P49
Monitor Value
Calculation Method
00: Normal
01: Fast
P52 Weld Time
00: Slope Time Excluded
01: Slope Time Included
P60 Minimum Current
00: Settable from 10% of full scale.
01: Settable from 2.5% of full scale.
P61 Displacement polarity
00: Set the force-applying direction as
plus.
01: Set the force-applying direction as
minus.
