IPB-5000B
11. Specifications
11-5
IPB-5000B-00-03/04/05
Displacement
Measurement Range
30.000mm Max.
Measurement
+/-15μm
Displacement Sensor
(Option)
GS-1830A manufactured by Ono Sokki Co. Ltd.
GS-1813A manufactured by Ono Sokki Co. Ltd.
LGK-110* manufactured by Mitutoyo Corp.
ST1278* manufactured by HEIDENHAIN
* An optional conversion cable is necessary.
Displacement Monitor
Setting Range
Upper/Lower Limit Setting Range of Final Displacement:
-29.999mm to +29.999mm (0.001mm ea.)
Workpiece Detection
At the end of Squeeze, the displacement is checked to confirm
whether or not a workpiece is set.
Up
per/Lower Limit Setting Range of workpiece detection:
-29.999mm to +29.999mm (0.001mm ea.)
Weld Stop
When WE1 or WE2 reaches the designated value of
Displacement, WE1 moves to CO and WE2, to HO.
Displacement Setting Range of Weld Stop: -
+29.999mm (0.001mm ea.)
Envelope
Possible to set Upper/Lower Limit Setting to Displacement
waveform
To Next Page
