IPB-5000B
11. Specifications
11-4
Items Common Specification in IPB-5000B
Starting Time of
detecting No Current
or No Voltage
Set at NO CURR MONITOR START.
00 to 10ms
(Starts to detect No Current or Voltage after the set period)
Pulse Monitoring
Start Time
Set at PW MONITOR START.
00 to 10ms (Starts the pulse monitoring after the set period)
NG Output Setting
Set at NG OUTPUT.
NORMALLY CLOSE:
Closed with Power Supply turned on
and open with NG generated
NORMALLY OPEN: Closed with NG generated
READY Output
Setting
Set at READY OUTPUT.
WELD ON: Closed with Weld Current Supply ready
POWER ON: Closed with IPB-5000B turned on
Accuracy of
Constant Current
+/-3%, Full Scale (Designated Condition / Fixed
Load) at the
case of setting and monitoring
Accuracy of
Constant Voltage
+/-
3%, Full Scale (Designated Condition / Fixed Load) at the
case of setting and monitoring
Duty Cycle
See the duty cycle graph in the operation manual for the welding
transformer in use IT*-360*6 or IT*-780*6.
Operation
Environment
Temperature: 5 to 40°C
Humidity: 90% or less (No condensation)
Altitude: 1000 meters or lower
Caution: Use this product in the environment without conductive
dust.
If conductive dust enters in the product, this may
result in a failure, electric shock
, or fire. When using
this product in this environment, make contact with us.
Storage
Environment
Temperature -10°–55°C and dew condensation not allowed
Heat-Resistant Class
E
Case Protection
IP20
IPB-5000B-00-00/03/07
IPB-5000B-00-01/02/04/05
Weld Power Supply
Three-phase, 200 to 240 V AC
±10% (50
Hz / 60 Hz)
(Voltage cannot be selected.
Fixed to a customer-specified
voltage in factory shipment.)
Three-phase, 380 to 480 V AC
±10% (50
Hz / 60 Hz)
(Voltage cannot be selected.
Fixed to a customer-specified
voltage in factory shipment.)
IPB-5000B-00-00/01/03/04/07
IPB-5000B-00-02/05
Outline dimensions
(mm)
269 (H) x 172 (W) x 470 (D)
(No projections included)
349 (H) x 172 (W) x 470 (D)
(No projections included)
Mass (kg)
15 19
