IPB-5000B
11. Specifications
11-3
Items
Common Specification in IPB-5000B
Counter
Set at COUNTER. Count-up Output is produced when the
counting arrives at Pre-set value for each mode.
(1) TOTAL (Total Counter Mode)
Every time the weld current is supplied, Count-up (+1
increment) is performed regardless of a judgment result.
Counter Pre-set Setting Range: 000000 to 999999
(2) GOOD (Good Product Counter Mode)
Every time GOOD is judged, Count-up is performed
Counter Pre-set Setting Range: 000000 to 999999
(3) WORK (Production Counter Mode)
Every time the counting arrives at the set value of Weld
Counter, WORK Count is counted- up (+1 increment).
When the monitored value is judged as No Good,
Count-up is not performed.
WELD Counter Pre-set Setting Range: 00 to 99
WORK Counter Pre-set Setting Range:
000000 to 999999
Note: The period for retaining the memory of counted numbers
is approximately 10 days since the day when a power
supply is turned off at latest.
Start Signal
Stabilizing Period
Set at START SIG. TIME.
Weld Sequence is started after finding the set value of 1, 5, 10
or 20ms and the Start Signal.
Self-sustaining
Method
Set at START SIG. HOLD.
NO HOLD: No self-sustaining action
WE HOLD: Self-sustaining action works from the start of
current supply
SQ HOLD: Self-sustaining action works from the start of SQD
Schedule Select
Method
Set at SCHEDULE#.
EXT. (NP): Selected by the use of binary data
EXT. (P): Selected by binary data with odd-numbered parity
PANEL: Selected on Panel
Period for outputting
END or GOOD Signal
Set at END SIG. TIME.
Output for 10ms, 100ms or the period during which Start Signal
is input (Note: if it is input 10ms or less, END or GOOD Signal is
output for 10ms.).
HOLD: Output for period during which Start Signal is input
10ms: Output for 10ms
100ms: Output for 100ms
Monitor Computing
Range
Set at MONITOR MODE.
EXCLUDE SLOPE: Computing a monitored value excluding
Slope Period
INCLUDE SLOPE : Computing a monitored value including
Slope Period
PARITY/WE1STOP
Input Selection
Set at SCHEDULE#.
EXT. (P): Parity Input at External Input Terminal Pin 14
EXT. (NP) or PANEL: WELD1 Stop Input at External Input
Terminal Pin 14
