IPB-5000B
11. Specifications
11-2
Items
Common Specification in IPB-5000B
Current Setting Range
Maximum current setting
Transformer
Setting range
NORMAL
(From 10 to 100% of
Transformer maximum current)
IT*-360*6
0.40 to 4.00kA
IT*-780*6
0.60 to 6.00kA
LOW
(From 2.5 to 100% of
Transformer maximum current)
IT*-360*6
0.10 to 4.00kA
IT*-780*6
0.15 to 6.00kA
The maximum current available for welding depends on the
load such as the welding head used. When you use a general
welding head, the approximate maximum current is 3000A for
IT*-360*6 and 4000A for IT*-780*6
. Also, in LOW mode, the
set current may not flow when the current less than 400A for
IT*-360*6 or 600A for IT*-780*6 is set.
Voltage Setting Range
0.30 to 9.99V
Power Setting Range
00.2 to 20.0kW (POWER-H)
0.10 to 9.99kW (POWER-L)
* POWER-H, POWER-L indicates Constant Power Control.
Monitor
IPB-5000B holds the monitored value of all schedules (only
the latest one for waveform) while the power is on.
When the power is turned off, all values are cleared.
Resistance
PRE-CHECK Function
Weld Time Setting Range: 00.0 to 10.0ms (0.2ms ea.)
Voltage Setting Range: 0.30 to 9.99V (0.01V ea.)
Current Upper/Lower Limit: 0.00 to 9.99kA (0.01kA ea.)
Monitor Upper/Lower
Limit Setting Range
Current: 0.00 to 9.99kA (0.01kA ea.)
Voltage: 0.00 to 9.99V (0.01V ea.)
Power (POWER-H)*: 00.0 to 20.0kW (0.1kW ea.)
(POWER-L)*: 0.00 to 9.99kW (0.01kW ea.)
Resistance: 00.0 to 99.9mΩ (0.1mΩ ea.)
Weld Time: 000.0 to 500.0ms (0.2ms ea.)
* POWER-H, POWER-L indicates Constant Power Control.
Envelope
Upper/Lower Limit setting is possible for the only one
waveform selected among Current, Voltage, Power and
Resistance.
Weld Stop
When WE1 or WE2 reaches the designated value of Current
or Voltage, WE1 moves to CO and WE2, to HO.
Setting Range of Weld Stop Current Value
IT*-360*6: 0.40 to 4.00kA
IT*-780*6: 0.60 to 6.00kA
Setting Range of Weld Stop Voltage Value
: 0.30 to 9.99V
