In order to prevent the danger of being caught in the die, firstly prevent entry into the
hazardous area, and if it is impossible, adopt a light curtain or the like to stop the press
machine.
If insertion of workpieces or removal of processed parts cannot be automated, it is the basic
protection that you do not need to put a part of your body into a hazardous area by using
manual tools.
2. Protection examples
2-1. Basic protection method
6
Protection
examples
Movable front guard
Light curtain
Before installing a guard or safety device, you need to sufficiently consider the physique and
working posture of workers.
You must determine the protection height so that a part of body does not reach the
hazardous area beyond the upper limit of the protection range of guards or light curtain.
2-2. Measures against entry from outside (beyond upper limit) of protection range
Movable front guard
Protection
examples
Light curtain
(with extended protection height)
