When installing a machine, secure adequate maintenance space around the machine.
If the press machine cannot be inspected and maintained adequately, the machine and safety
devices will not function properly, which will impair safety.
The figure below is the minimum maintenance space required in the front, rear, left and right of
the press machine.
(Refer to the catalog for details since the machine dimensions differ according to the model and
specifications of the machine.)
1-2. Installation space
5
Necessary
maintenance
space
1.5 m or more
1.5 m or more
1.5 m or more
1.5 m or more
