Coil Cover Coil Cover ID Bl ower ID Bl ower
Set Point on Max Make Set Poi nt on Max Make
Pres sure Fa l l On Pressure Press ure Fa l l On Pressure
(PF) W.C. Ri se W.C. (PF) W.C. Ri se W.C.
*MES960403ANAA
- 0.10 ± .05 - 0.25 - 0.35 ± .05 - 0.50 0130F00642
*MES960603BNAA
- 0.10 ± .05 - 0.25 - 1.49 ± .07 - 1.70 0130F00478
*MES960803BNAA
- 0.10 ± .05 - 0.25 - 1.27 ± .07 - 1.48 0130F00477
*MES960804CNAA
- 0.10 ± .05 - 0.25 - 1.27 ± .07 - 1.48 0130F00477
*MES960805CNAA
- 0.10 ± .05 - 0.25 - 1.27 ± .07 -1.48 0130F00477
*MES961004CNAA
- 0.10 ± .05 - 0.25 - 1.27 ± .07 - 1.48 0130F00477
*MES961205DNAA
- 0.10 ± .05 - 0.25 - 0.85 ± .05 - 1.00 0130F00476
*CES960403BNAA
- 0.08 ± .04 - 0.16 - 1.49 ± .07 - 1.70 0130F00484
*CES960603BNAA
- 0.10 ± .05 - 0.25 - 1.49 ± .07 - 1.70 0130F00477
*CES960804CNAA
- 0.10 ± .05 - 0.25 - 1.49 ± .07 - 1.70 0130F00477
*CES961005CNAA
- 0.10 ± .05 - 0.25 - 1.49 ± .07 - 1.70 0130F00477
*CES961205CNAA
- 0.10 ± .05 - 0.25 - 0.85 ± .05 - 1.00 0130F00476
*MES96 / *CES96 Pressure Switch Trip Points And Usage Chart
Model
ID Bl ower
Coil Cover
Pres sure
Swi tch
Assembly
Part #
Model
Coil Cover
Set Point on
Pressure Fall
(PF) W.C.
Coil Cover
Max Make
On Pressure
Rise W.C.
ID Blower
Set Point on
Pressure Fall
(PF) W.C.
ID Blower
Max Make
On Pressure
Rise W.C.
ID Blower
Coil Cover
Pressure Switch
Assembly Part #
*MES920403ANAA - 0.10 ± .05 -0.25 - 0.20 ± .05 -.035 0130F00641
*MES920603BNAA - 0.10 ± .05 -0.25 - 1.20 ± .05 -1.41 0130F00480
*MES920803BNAA - 0.10 ± .05 -0.25 - 0.97 ± .05 -1.12 0130F00479
*MES920804CNAA - 0.10 ± .05 -0.25 - 1.20 ± .05 -1.41 0130F00480
*MES920805CNAA - 0.10 ± .05 -0.25 - 1.20 ± .05 -1.20 0130F00480
*MES921004CNAA - 0.10 ± .05 -0.25 - 0.97 ± .05 -1.12 0130F00479
*MES921005CNAA - 0.10 ± .05 -0.25 - 0.97 ± .05 -1.12 0130F00479
*MES921205DNAA - 0.10 ± .05 -0.25 - 1.20 ± .05 -1.41 0130F00480
*MES92 Pressure Switch Trip Points And Usage Chart
