SERVICING
34

 
  
 





System Will Not Start
Burner Won't Ignite
Burner Ignites-Locks Out
Burner Shuts Off prior to T'Stat being Satisfied
Short Cycles
Long Cycles
Soot and /or Fumes
Too Much Heat
Not Enough Heat



Pow er Failure
●
Test Voltage S-1
Blow n Fuse
●
Test Voltage S-4
Loose Connection
●
Check Wiring S-2
Shorted or Broken Wires
●
Check Wiring S-3A
No Low Voltage
●
Check Transformer S-4
Faulty Thermostat
● ● ● ● ●
Check Thermostat S-3A
Faulty Transformer
●
Check Transformer S-4
Poor or High Resistance Ground
●
Measure Ground Resistance S-17B
Improper Heat Anticipator Setting
● ● ● ●
Adjust Heat Anticipator Setting S-3B
Improper Thermostat Location
● ● ● ●
Relocate Thermostat S-316
Faulty Limit or Roll Out Sw itch
● ●
Test Control S-300 / S-302
Faulty Flame Sensor
●
Test Flame Sensor S-314
Faulty Ignition Control
● ● ●
Test Control S-313
Gas Valve or Gas Supply Shut Off
●
Turn Valves to On Position S-317
Faulty Induced Draf t Blow er
● ●
Test Induced Draf t Motor S-303
Faulty Blow er Motor
● ●
Test Blow er Motor S-16A,B,C
Broken or Shorted Ignitor
●
Test Ignitor S-308
Dirty Flame Sensor, Low UA
●
Clean Flame Sensor S-314
Stuck Gas Valve
● ● ●
Replace Gas Valve S-304
Faulty Gas Valve
● ● ●
Replace Gas Valve S-304
Open Auxiliary Limit
● ●
Reset Control S-301
Improper Air Flow or Distribution
● ●
Check Duct Static S-200
Cycling on Limit
● ● ●
Check Controls & Temperature Rise S-201 / S-300
Delayed Ignition
●
Test for Delayed Ignition S-312
Flashback
●
Test for Flashback S-309 / S-311
Orif ice Size
● ● ●
Check Orifices S-306 / S-311
Gas Pressure
● ● ● ●
Check Gas Pressure S-307
Cracked Heat Exchanger
●
Check Burner Flames S-305
Furnace Undersized
● ●
Replace w ith Proper Size Furnace S-318
Furnace Oversized
●
Replace w ith Proper Size Furnace S-318
Faulty Pressure Sw itch
● ● ●
Test Pressure Sw itch S-310
Blocked or Restricted Flue
●
Check Flue/Draw dow n Pressure S-310
Open Roll Out Sw itch
● ●
Test Flame Roll Out Control S-302
Bouncing On Pressure Sw itch
●
Test Negative Pressure S-310
