ACCESSORIES
83
For heater kit installation, it is important to set the capacity of the electric heater at Set-up menu on the thermostat and
DIP switch on indoor unit control board. For more information, please see indoor unit I/O manual.
+For match up with a 2 ton outdoor unit: Heater kit application shall not exceed 10 kW.
++For match up with a 3 ton outdoor unit: Heater kit application shall not exceed 15 kW.
NOTE: For emergency mode heating, set the dipswitch on PCB. For heating mode, use the thermostta user menu.
Selection AVPEC25B14A* AVPEC37C14A* + AVPEC59D14A* ++ AVPEC61D14A* S-9 S-10 S-11 S-12
No heater - - - - OFF OFF OFF OFF
Fi rs t 3 5 5 5 ON ON ON ON
Second 5 6 6 6 ON ON ON OFF
Thi rd 6 8 8 8 ON ON OFF ON
Fourth 8 10 10 10 ON ON OFF OFF
Fi fth 10 15 15 15 ON OFF ON ON
Si xth X 19 20 20 ON OFF ON OFF
Seventh X X X 25 ON OFF OFF ON
Dip Switch Setting Indoor PCB DS Bank 3
