ACCESSORIES
85
3 5 6 8 10 15 19/20 25
800 10 17 21 28 33
1000 8 13 17 22 27 40
1200 7 11 14 19 22 33 45 56
1400 6 10 12 16 19 29 38 48
1600 5 8 10 14 17 25 33 42
1800 5 7 9 12 15 22 30 37
2000 4 7 8 11 13 20 27 33
CFM
HEAT KIT NOMINAL kW
208/1/60 SUPPLY VOLTAGE - TEMP. RISE °F
3 5 6 8 10 15 19 20 25
AVPEC25B14* 550 650 700 715 875
AVPEC37C14* 850 900 1000 1120 1220 1250
AVPEC59D14* 990 1110 1200 1240 1520 1520
AVPEC61D14* 1030 1150 1250 1320 1650 1690 1715
Model
HEATER (kW)
MINIMUM CFM REQUIRED FOR HEATER KITS
HTR
KW
3.0
KW
4.7
KW
6.0
KW
7.0
KW
9.5
KW
14.2
KW
19.5
KW
21.0
KW
BTUH 10200 16200 20400 23800 32400 48600 66500 71600
ELECTRIC HEATER CAPACITY BTUH
FORMULAS:
Heating Output = KW x 3.413 x Corr. Factor
Actual CFM = CFM (from table) x Corr. Factor
BTUH = KW x 3.413
BTUH = CFM x 1.08 x Temperature Rise (T)
CFM = KW x 3.413
1.08 x T
T = BTUH
CFM x 1.08


Each individual heater element is protected with a one time
fuse link which is connected in series with the element. The
fuse link will open at approximately 333°.


1. Remove heater element assembly so as to expose fuse
link.
2. Using an ohmmeter, test across the fuse link for conti-
nuity - no reading indicates the link is open. Replace as
necessary.
NOTE: The link is designed to open at approximately
333°F. DO NOT WIRE AROUND - determine reason for
failure.
