10
28" (71.1 cm)
26.9" (68.3 cm)
14.6"
(37.1 cm)
36.6" (93 cm)
43.6" (110.7 cm)
30.9" (78.5 cm)
28" (71.1 cm)
16.8"
(42.7 cm)
2"
(5.1 cm)
Installing Washer
7. Check Installation
Refer to Installer Check on back cover of this manual
and make sure that washer is installed correctly.
8. Verify Washer Operation
Push timer knob in and turn to RINSE & SPIN cycle
to ensure washer is operating correctly. Close door
and pull knob out to start the washer. Verify that
water enters the wash tub, the wash tub rotates,
water is drained out and the wash tub spins dry.
Verify washer operation
Rough in Dimensions
