Amana MVC80 User Manual

31
menu oPtionS
LED Display Menu Description LED Display Menu Description

Enable or disable inverter boost operation. (compressor speed may
increase when this feature is on) (inverter only)

Gas Heat Airflow Trim (default = 0%)

Boost mode will operate above this selected temperature. On =
boost mode always on (default = 105°F) (inverter only)

Maximum Compressor Run Time Between Defrost Cycles (default
= 120 minutes)

Cooling Airflow Profile setting (default = profile D shown as 4)

Heat Pump Heating Airflow Off Delay Time (default = 60 seconds)

Heat Pump compressor lockout temperature. Furnace will act as
primary heat source below this temperature. (Default = 45°F)

Heat Pump Heating Airflow On Delay Time (default = 5 seconds)

Compressor off delay at the beginning and end of a defrost cycle.
(default = 30 seconds)

Select the range that includes the desired compressor RPS for
inverter heating operation. See inverter manual for menu options

Cooling Airflow Off Delay Time. (default = 60 seconds)

Maximum Compressor RPS for Heating Mode (inverter only)

Resets all cooling settings to factory default.

Reset all heat pump heating settings to factory default.

Cooling Airflow On Delay Time (default = 5 seconds)

Percentage of high stage heat pump heating airflow to run during
low stage operation. (default = 70%)

Control Firmware Revision Number

Heat Pump Indoor Airflow Trim (default = 0%)

Enable or disable inverter charge mode.

High Heating Airflow Trim for Inverter Units. See inverter manual for
menu options and defaults

Select the range that includes the desired compressor RPS for
inverter cooling operation. See inverter manual for menu options

Intermediate Heating Airflow Trim for Inverter Units. See inverter
manual for menu options and defaults

Maximum Compressor RPS for cooling mode. (inverter only)

Low Heating Airflow Trim for Inverter Units. See inverter manual for
menu options and defaults

Percentage of high stage cooling airflow to run during low stage
operation. (default = 70%)

View 6 most recent fault codes and clear all fault codes if desired.
(furnace)

Cooling Airflow Trim (default 0%)

Restart communications between the indoor and outdoor unit.

High Cooling Airflow Trim for inverter units. See inverter manual for
menu options and defaults

Select the number of stages for the non-communicating outdoor
unit. Default = OFF meaning no outdoor unit.

Intermediate Cooling Airflow Trim for inverter units. See inverter
manual for menu options and defaults

Enable Pump Down Mode

Low Cooling Airflow Trim for inverter units. See inverter manual for
menu options and defaults

Resets furnace settings to factory defaults.

Compressor run time between defrost cycles. (default = 30
minutes) (2 stage units)

Maximum Current Option (system will limit capacity to percentage
of maximum current) (default = 100%)

Enables or disables dehumidification feature in the outdoor unit.
(default = Enabled)

Control Shared Data Revision Number

Select "1" to enable dehumidification when the thermostat DH
terminal is energized. Select "0" to enable dehumidification when
the thermostat DH terminal is de-energized. (default = 1)

Resets all outdoor unit settings to factory defaults.

Gas heat operation during defrost. 1 = low heat, 2 (default) = high
heat

System Verification Test (inverters only)

View 6 most recent fault codes and Clear Fault Codes if desired
(outdoor communicating units)

Indoor Airflow for non-communicating outdoor units. (values based
on 400CFM per ton) (default = 3.0 Ton)

Force system into a defrost cycle (inverter units)

Select Outdoor Unit Elevation (SL=same level, OL = outdoor lower,
IL = indoor lower) Default = Outdoor Lower

Constant Fan Speed as percent of maximum airflow. Default =
25%

1 = system will try to satisfy the thermostat quickly.
5 (default) = system will try to satisfy the thermostat more slowly.

Gas Heat Airflow (percentage of maximum system airflow)

Menu is enabled if the  menu is set to 6. Select the target time
the system will attempt to satisfy the thermostat.

Gas Heat Fan Off Delay (default = 90 seconds)

Menu is enabled if the  menu is set to 6. Select the percentage
past the target time when the system will transition to gas furnace
operation during heat mode.

Gas Heat Fan On Delay (default = 30 seconds)

Menu is enabled if the  is set to 6. (the gas furnace will run
during the next heat call if the heat pump fails to satisfy the
custom target time for this number of consecutive cycles) (default
= 20 cycles)

Enables gas heat at 100% for pressure testing during
commissioning.

Menu is enabled if the  menu is set to 6. (if low stage gas heat
is able to consecutively satisfy the thermostat under the set target
time for this number of cycles, the system will transition to the
heat pump for primary heating)

Percentage of high stage gas heating airflow to run during low
stage gas heat operation. (default = 70%)

Menu is enabled if the  menu is set to 6. (this percentage will
help determine when switching back to heat pump operation is
appropriate. Default = 20%. If target time = 20 minutes, low stage
furnace operation must satisfy the thermostat by less than 16
minutes. (target time - 20% default = 16 minutes).
