Amana PTH123G User Manual

Functional Parts
Part
No:
Description:
20406303 BASE PAN VALVE (M1, M2, M3, M4, M5, M6,
M7, M8, M9, M10, M11, M13, M14, M15, M16,
M17, M18, M19, M20, M21, M22, M23)
CAP030300450RS CAPACITOR, 500V
44A282A COMPRESSOR, RECHI
RSKP0010 CONTROL BOARD M61
RSKP0005 CONTROL PANEL COVER AND MEMBRANE
0130P00059 CORD, 250VAC, 15A (LCD) (M1, M2, M3, M4,
M5, M6, M7)
0130P00058 CORD, 250VAC, 20A (LCD) (M8, M9, M10,
M11, M12, M13, M14, M15, M16)
0130P00061 CORD, 250VAC, 30A (LCD) (M17, M18, M19,
M20, M21, M22)
0131P00029 FAN MOTOR, INDOOR
0131P00031 FAN MOTOR, OUTDOOR
0161P00030 FAN, CONDENSER
0275P00039 HEATER ASSY (M17, M18, M19, M20, M21,
M22, M23)
0275P00038 HEATER ASSY (M8, M9, M10, M11, M12, M13,
M14, M15, M16)
0275P00019 HEATER ASSY (M1, M2, M3, M4, M5, M6, M7)
0130M00132 HIGH PRESSURE SWITCH
11172801 POWER VENT MOTOR (M3, M4, M7, M11,
M16, M19, M22)
0130M00096 RELAY
C8873917 RELAY (HYDRONIC) (M12)
C8873932 RELAY (POWER VENT) (M3, M4, M7, M11,
M16, M19, M22)
0151P00000 REVERSING VALVE ASSY-230V
0130P00022 REVERSING VALVE COIL
0130P00098 THERMISTOR (M3, M6, M9, M13, M15, M21)
0130P00074 THERMISTOR
0130P00077 THERMISTOR (M3, M6, M9, M13, M15, M21)
0130P00086 THERMISTOR, .312 CLIP, RED
0130P00093 THERMISTOR, .375 CLIP, BLUE
0130P00075 THERMISTOR-DISCHARGE
B1378501 TRANSFORMER (M3, M4, M7, M11, M16, M19,
M22)
0130M00078 TRANSFORMER (M12)
20512501 TRANSFORMER (HYDRONIC)
PCBEP100 VARIABLE SPEED TERMINAL BOARD
0150P00004 WHEEL, BLOWER
Expanded Model Nomenclature
M1 - PTH123G25AXXXAA
M2 - PTH123G25CXXXAA
M3 - PTH123G25DRXXAA
M4 - PTH123G25DXXXAA
M5 - PTH123G25QXXXAA
M6 - PTH123G25RXXXAA
M7 - PTH123G25VXXXAA
M8 - PTH123G35AXXXAA
M9 - PTH123G35CRXXAA
M10 - PTH123G35CXXXAA
M11 - PTH123G35DXXXAA
M12 - PTH123G35PXXXAA
M13 - PTH123G35QRXXAA
M14 - PTH123G35QXXXAA
M15 - PTH123G35RXXXAA
M16 - PTH123G35VXXXAA
M17 - PTH123G50AXXXAA
M18 - PTH123G50CXXXAA
M19 - PTH123G50DXXXAA
M20 - PTH123G50QXXXAA
M21 - PTH123G50RXXXAA
M22 - PTH123G50VXXXAA
M23 - PTH123G50WXXXAA
3
RP-735C
www.goodmanmfg.com
www.amana-hac.com
