Amana PTH123G User Manual

Front Assy
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
FRONT-DICHARGE LOUVERS 0161P0003311
CONTROL BOARD M61 RSKP0010
21
TRANSFORMER (HYDRONIC) 20512501
31
CLIP (QTY 2)0163P00025
41
CONTROL PANEL COVER 0121P00001P
51
SCREEN, DISCHARGE 0121P00073
61
DOOR ASSY -AMANA- 0261P00003
71
FRONT ASSY 0261P00011
81
TRANSFORMER (M12)0130M00078
111
TRANSFORMER (M3, M4, M7, M11, M16, M19,
M22)
B1378501
111
RELAY 0130M00096
121
RELAY (HYDRONIC) (M12)C8873917
121
RELAY (POWER VENT) (M3, M4, M7, M11, M16,
M19, M22)
C8873932
121
DIGITENNA (M3, M6, M9, M13, M15, M21)1261401
261
PADDLE SWITCH (M3, M4, M7, M11, M16, M19,
M22)
B1337701
291
VARIABLE SPEED TERMINAL BOARD PCBEP100
301
FILTER, RACK (QTY 2)0161P00035
NS
TERMINAL BOARD (M3, M4, M7, M11, M16, M19,
M22)
B1160701NS
Expanded Model Nomenclature
M1 - PTH123G25AXXXAA
M2 - PTH123G25CXXXAA
M3 - PTH123G25DRXXAA
M4 - PTH123G25DXXXAA
M5 - PTH123G25QXXXAA
M6 - PTH123G25RXXXAA
M7 - PTH123G25VXXXAA
M8 - PTH123G35AXXXAA
M9 - PTH123G35CRXXAA
M10 - PTH123G35CXXXAA
M11 - PTH123G35DXXXAA
M12 - PTH123G35PXXXAA
M13 - PTH123G35QRXXAA
M14 - PTH123G35QXXXAA
M15 - PTH123G35RXXXAA
M16 - PTH123G35VXXXAA
M17 - PTH123G50AXXXAA
M18 - PTH123G50CXXXAA
M19 - PTH123G50DXXXAA
M20 - PTH123G50QXXXAA
M21 - PTH123G50RXXXAA
M22 - PTH123G50VXXXAA
M23 - PTH123G50WXXXAA
5
RP-735C
www.goodmanmfg.com
www.amana-hac.com
