Amana PTH123G User Manual

Chassis Control Panel
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
SHROUD, CONDENSER 0161P0002611
FAN MOTOR, OUTDOOR 0131P00031
21
PANEL-PARTITION (M5, M13, M14, M20)0121P00093
31
PANEL-PARTITION PNT (M2, M9, M10, M18)0121P00108DG
31
FAN, CONDENSER 0161P00030
41
CABLE 0163P00019
51
BRACKET, VENT DOOR (M3, M4, M7, M11, M16,
M19, M22)
0121P00079
61
BRACKET, VENT DOOR-C (M1, M2, M6, M8, M9,
M10, M12, M15, M17, M18, M21, M23)
0121P00072DG61
VENT DOOR (M2, M9, M10, M18)11046105PDG
71
PARTITION PANEL BRACKET (QTY 2)11191703
81
LEVER ARM (M1, M2, M6, M8, M9, M10, M12, M15,
M17, M18, M21, M23)
1104630291
THERMISTOR (M3, M6, M9, M13, M15, M21)0130P00098
101
POWER DOOR ASSY (M3, M4, M11, M19)0270P00997
191
BRKT, POWER VENT (M3, M4, M7, M11, M16,
M19, M22)
0121P00080NS
EXTENSION SPRING (M3, M4, M7, M11, M16,
M19, M22)
11166401
NS
PANEL-AUXILLIARY (M5, M13, M14, M20)0121P00091NS
POWER VENT COVER BRACKET (M3, M4, M7,
M11, M16, M19, M22)
11166201
NS
POWER VENT MOTOR (M3, M4, M7, M11, M16,
M19, M22)
11172801
NS
POWER VENT MOTOR BRACKET (M3, M4, M7,
M11, M16, M19, M22)
11166101NS
Expanded Model Nomenclature
M1 - PTH123G25AXXXAA
M2 - PTH123G25CXXXAA
M3 - PTH123G25DRXXAA
M4 - PTH123G25DXXXAA
M5 - PTH123G25QXXXAA
M6 - PTH123G25RXXXAA
M7 - PTH123G25VXXXAA
M8 - PTH123G35AXXXAA
M9 - PTH123G35CRXXAA
M10 - PTH123G35CXXXAA
M11 - PTH123G35DXXXAA
M12 - PTH123G35PXXXAA
M13 - PTH123G35QRXXAA
M14 - PTH123G35QXXXAA
M15 - PTH123G35RXXXAA
M16 - PTH123G35VXXXAA
M17 - PTH123G50AXXXAA
M18 - PTH123G50CXXXAA
M19 - PTH123G50DXXXAA
M20 - PTH123G50QXXXAA
M21 - PTH123G50RXXXAA
M22 - PTH123G50VXXXAA
M23 - PTH123G50WXXXAA
7
RP-735C
www.goodmanmfg.com
www.amana-hac.com
