Amana PTH123G User Manual

Partition Assy
Ref.
No:
Part
No:
Description:
Ref.
No:
Part
No:
Description:
Image 1:
BASEPAN, PNT 0121P00056DG11
PLASTIC-DRAIN PAN 0161P00044
21
CAPACITOR STRAP C6300502
51
TOP, PARTITION PANEL PNT 0121P00063DG
71
CAPACITOR, 500V CAP030300450RS
81
BRACE, TIE PNT (QTY 2)0121P00071DG
101
CORD, 250VAC, 15A (LCD) (M1, M2, M3, M4, M5,
M6, M7)
0130P00059
121
CORD, 250VAC, 20A (LCD) (M8, M9, M10, M11,
M12, M13, M14, M15, M16)
0130P00058121
CORD, 250VAC, 30A (LCD) (M17, M18, M19, M20,
M21, M22)
0130P00061
121
CONTROL PANEL COVER AND MEMBRANE RSKP0005131
PLASTIC-HOOD 0161P00016
141
ACCESS COVER 20410801
151
CUTOFF-SCROLL DG 0121P00061DG
161
COVER, MOTOR PNT 0121P00070DG171
MID PARTITION PANEL 20403301
NS
SEAL-L SIDE PTC 20416201
NS
SEAL-R SIDE PTC 20416101
NS
Expanded Model Nomenclature
M1 - PTH123G25AXXXAA
M2 - PTH123G25CXXXAA
M3 - PTH123G25DRXXAA
M4 - PTH123G25DXXXAA
M5 - PTH123G25QXXXAA
M6 - PTH123G25RXXXAA
M7 - PTH123G25VXXXAA
M8 - PTH123G35AXXXAA
M9 - PTH123G35CRXXAA
M10 - PTH123G35CXXXAA
M11 - PTH123G35DXXXAA
M12 - PTH123G35PXXXAA
M13 - PTH123G35QRXXAA
M14 - PTH123G35QXXXAA
M15 - PTH123G35RXXXAA
M16 - PTH123G35VXXXAA
M17 - PTH123G50AXXXAA
M18 - PTH123G50CXXXAA
M19 - PTH123G50DXXXAA
M20 - PTH123G50QXXXAA
M21 - PTH123G50RXXXAA
M22 - PTH123G50VXXXAA
M23 - PTH123G50WXXXAA
9
RP-735C
www.goodmanmfg.com
www.amana-hac.com

Amana PTH123G Specifications

General

Brand	Amana
Model	PTH123G
Category	Heat Pump
Language	English
