Troubleshooting
Cook Condition
Push pad number 1,
pad beeps when pushed.
Open oven door.
Oven is operatin
g
properl
y
.
Yes
Water placed in oven is properl
y
heated?
Heats very slowly.
NOTE : Verif
y
b
y
performin
g
power test (pa
g
e 26).
Inoperative hi
g
h volta
g
e transformer(s).
Inoperative diode(s).
Inoperative capacitor(s).
Inoperative ma
g
netron(s).
Inoperative or misadjusted interlock switch module.
Inoperative triac(s).
Inoperative ma
g
netron thermal cutout.
Broken or improper wire connection.
1.
2.
3.
4.
5.
6.
7.
8.
No heat.
Inoperative or misadjusted interlock switch module.
Inoperative ma
g
netron thermal cutouts.
Inoperative capacitors.
Inoperative hi
g
h volta
g
e board.
Inoperative hi
g
h volta
g
e transformers.
Broken or improper wire connections.
1.
2.
3.
4.
5.
6.
NO
Place a cup of water in oven and
close door.
Flashing
Yes
Error code appears after about 8 seconds?
Refer to Display Dia
g
nostics.
Displa
y
starts countin
g
down?
Inoperative low volta
g
e board.
Inoperative interlock switch module.
Broken or improper wire connection.
1.
2.
3.
NO
Note: There will be a 2 to 3
second delay before display
begins counting down.
Note:
"ITEM"
must be flashing
or the door has to be opened
and closed to reactivate a
cook condition.
Beep not pro
g
rammed into oven.
Inoperative touch panel.
Pad not pro
g
rammed.
Door not completely latched.
1.
2.
NO
Inoperative interlock switch module.
Broken or improper wire connections.
NO
3.
4.
1.
2.
