AmazonBasics B073Q48YGF User Manual

9
Model Standby UPS 600VA Standby UPS 800VA
Max. Load for Full-Time Surge
Protection outlets
10 Amps
On-Battery Output Wave Form Simulated Sine Wave
Operating Temperature + 32 °F to 104 °F / 0 °C to 40 °C
Operating Relative Humidity 0 to 95% non-condensing
Size (L x W x H)
10.7 x 3.1 x 6.1 in.
(272 x 80 x 155 mm)
12.2 x 3.1 x 7.0 in.
(310 x 80 x 178 mm)
Net Weight 6.53 lbs (2.96 kg) 9.23 lbs (4.18 kg)
Typical Battery Recharge Time 8 hours typical from total discharge
Typical Battery Life
3 to 6 years, depending on number of discharge/
recharge cycles
Recommended Battery Sealed Maintenance Free Lead Acid Battery
Safety Approvals UL, cUL, FCC Class B, ICES-003: Class B, CEC
System Function Block Diagram
Input
Output
EMI Filter
Battery Inverter
Surge
Suppressor
Charger
AC / DC
Normal Mode
Battery Mode
