AMBIC Classic - Operation and Parts; Operation Instructions; Parts List Identification

9 pages

To Next Page

To Previous Page

. OPERATION

FIG. 11 FIG. 12

FIG. 13

FIG. 14

REF NO QTY DESCRIPTION

A ATS/401 1 Power Unit

3 Screws & Plugs

B ATS/413 1 Vacuum Pipe Adaptor

C/D ATS/412 1 Liquid Intake Pipe + Filter

E/F 1 18M Transparent Tubing

G ATS/407 3 T. Connectors

REF NO QTY DESCRIPTION

H ATS/402

ATS/502

3 Spray Guns

I ATS/406 3 Retractable Coil

J ATS/429 2 Blanking Plugs

K ATS/411 30 Cable Ties

5. PARTS LIST (refer to FIG. 1)
