Connect speakers and subwoofer, using the supplied waterproof
wire nuts. Make absolutely sure you always connect positive to
positive and negative to negative. And be sure to connect right and
left channels correctly.
If you wire Positive (+) to Negative (-), the system will not perform as
it should. Make all speaker connections and test the system BEFORE
burying the wire.
DIAGRAM  • LS KIT 3 | Resistor Wiring Diagram
Satellite Speaker wire
From SUBWOOFER
Use Waterproof
Wire Nuts
2-Conductor
Speaker Cable
(Not Included)
Satellite Speaker wire
2-Conductor Speaker Cable
(Not Included)
•Waterproof Wire nuts
•
•
•
8  RESISTOR
FROM SUBWOOFER
FROM SUBWOOFER TO SPEAKER
