Extend from the subwoofer to the LEFT satellite speaker.
At the LEFT satellite speaker, connect the RESISTOR in line with the
LEFT positive to LEFT positive wire and the LEFT negative to LEFT
negative wire.
Extend from the connected RESISTOR to the LEFT satellite speaker.
Connect the LEFT positive to the RED positive wire and the LEFT
negative to the BLACK negative wire of the LEFT satellite speaker.
See Diagram 5.
IV. Connect the RIGHT positive conductor from the amp, to the RIGHT
(Red Wire) input on the subwoofer.
Connect the RIGHT negative conductor from the amp, to the RIGHT
(Black Wire) input on the subwoofer.
Left Channel: WHITE = Positive | GREEN = Negative
Right Channel: RED = Positive | BLACK = Negative
Extend from the subwoofer to the RIGHT satellite speaker.Connect the
RESISTOR in line with RIGHT positive to the RIGHT positive wire and
the RIGHT negative to the RIGHT negative wire of the RIGHT satellite
speaker. See Diagram 5.
Extend from the connected RESISTOR to the RIGHT satellite speaker.
Connect the RIGHT positive to the RED positive wire and the RIGHT
negative to the BLACK negative wire on the RIGHT satellite speaker.
III. Connect the LEFT positive conductor from the amp, to the LEFT
positive (White Wire) input on the subwoofer.
Connect the LEFT negative conductor from the amp, to the LEFT
negative (Green Wire) input on the subwoofer.
