Neonate
Paediatric Adult
Resuscitator volume approx. 260 ml approx. 660 ml approx. 1546 ml
Delivered volume one hand** 150 ml 450 ml 600 ml
Delivered volume two hands** - - 1100 ml
Dimensions without
Reservoir (length x diameter)
approx.
198 x 75 mm
approx.
240 x 100 mm
approx.
269 x 130 mm
Weight without
Reservoir and Mask
approx. 128 g approx. 205 g approx. 338 g
Pressure-limiting valve* 4.0 kPa (40 cm H
2
O) 4.0 kPa (40 cm H
2
O) 4.0 kPa (40 cm H
2
O)
Dead space
≤ 5 ml + 10 % of
the delivered volume
≤ 5 ml + 10 % of
the delivered volume
≤ 5 ml + 10 % of
the delivered volume
Inspiratory resistance
max 0,5 kPa
(5,0 cm H
2
O)
at 5 l/min
max 0,5 kPa
(5,0 cm H
2
O)
at 50 l/min
max 0,5 kPa
(5,0 cm H
2
O)
at 50 l/min
Expiratory resistance
max 0,5 kPa
(5,0 cm H
2
O)
at 5 l/min
max 0,5 kPa
(5,0 cm H
2
O)
at 50 l/min
max 0,5 kPa
(5,0 cm H
2
O)
at 50 l/min
Reservoir volume
approx. 1500 ml (bag)
approx. 100 ml (tube
)
approx. 1500 ml (bag) approx. 1500 ml (bag)
Patient connector
Outside 22 mm male (ISO 5356-1)
Inside 15 mm female (ISO 5356-1)
Expiration connector
(for PEEP valve attachment)
30 mm male (ISO 5356-1)
Manometer Port connector Ø 4,2 +/- 0,1 mm
Bag inlet connector -
Inside 32mm female
(ISO10651-4)
Inside 32mm female
(ISO10651-4)
Forward and backward leakage Not measurable
Operation temperature -18 °C to +50 °C (-0.4 °F to +122 °F)
Storage temperature
Tested at - 40 °C (-40 °F) and + 60 °C (+140 °F)
according to EN ISO10651-4
O
2
inlet connector according to EN 13544-2
Long term storage
For long term storage the resuscitator should be kept in closed
packaging in a cool place away from sunlight.
* Higher delivery pressure can be obtained by overriding the pressure-limiting valve.
The Ambu Oval Plus Adult is also available without pressure-limiting valve.
** Tested according to EN ISO 10651-4.
4. Principle in operation
The illustration (1) shows the ventilation gas flow mixtures into the bag and to and
from the patient during manual operation of the resuscitator. (a) Adult and paedi-
atric resuscitator, (b) infant resuscitator with closed reservoir, (c) infant resuscitator
with open reservoir.
The gas flow is similar when the patient is breathing spontaneously through the
device. The O
2
reservoir assembly is fitted with two valves, one allowing ambient
air to be drawn in when the reservoir is empty and one spilling out surplus
oxygen when the reservoir bag is full.
1.1 Excess oxygen, 1.2 Air, 1.3 Oxygen inlet, 1.4 Patient, 1.5 Expiration,
1.6 Manometer port, 1.7 Pressure limiting valve,
5. Instructions for use
Preparation
- If the resuscitator is packed in a compressed state, unfold by pulling on
the patient valve and the inlet valve.
- Fit the facemask and place all items in the plastic bag supplied with
the resuscitator.
- The integrity of the kits issued for storage ready for use should be inspected
at the interval established in the local protocol.
- Before use on the patient make a brief functional test as described in section 9.
- If connecting external devices to the resuscitator, make sure to test for functionality
and consult the instructions for use accompanying the external device.
