AMCOT ST SERIES FIBERGLASS COOLING TOWER
- 33 -
GENERAL MAINTENANCE
Mechanical System – Fan Assembly
The following is the pitch chart for the adjustable fans on models ST-60 to ST-1500.
FAN PITCH FOR ST-60 TO ST-1500
MODELS
PITCH
MODEL
PITCH
ST-60
0
ST-300
+2
ST-70
0
ST-350
+2
ST-80
+1
ST-400
0
ST-100
+2
ST-500
0
ST-125
+2
ST-600
0
ST-150
-2
ST-700
0
ST-175
-2
ST-800
0
ST-200
-2
ST-1000
0
ST-225
+1
ST-1250
0
ST-250
+1
ST-1500
0
