AMCOT ST SERIES FIBERGLASS COOLING TOWER
- 34 -
GENERAL MAINTENANCE
Mechanical System – Fan Assembly
Fan Assembly Data
MODEL
FAN BLADE REFERENCE
NUMBER*
FAN DIAMETER
(INCHES)
TORQUE (FT-LBS) RATING
(Adjustable Fan Blades)
ST-3
LSF-050
19 1/2"
NA
ST-H-3
LSF-050
19 1/2"
NA
ST-5
LSF-050
19 1/2"
NA
ST-H-5
LSF-050
19 1/2"
NA
ST-8
LSF-050
19 1/2"
NA
ST-H-8
LSF-050
19 1/2"
NA
ST-10
LSF-070
26 3/8"
NA
ST-H-10
LSF-050
19 1/2"
NA
ST-15
LSF-070
26 3/8"
NA
ST-H-15
LSF-070
26 3/8"
NA
ST-20-1
LSF-080
30 1/4"
NA
ST-H-20-1
LSF-070
26 3/8"
NA
ST-20-3
LSF-080
30 1/4"
NA
ST-H-20-3
LSF-070
26 3/8"
NA
ST-25
LSF-080
30 1/4"
NA
ST-30
LSF-080
30 1/4"
NA
ST-40
LSF-100
38 1/4"
NA
ST-50
LSF-100
38 1/4"
NA
ST-60
LSF-120
46"
11
ST-70
LSF-120
46"
11
ST-80
LSF-120
46"
11
ST-100
LSF-150
57 7/8"
11
ST-125
LSF-150
57 7/8"
11
ST-150
LSF-180
68 7/8"
20
ST-175
LSF-180
68 7/8"
20
ST-200
LSF-180
68 7/8"
20
ST-225
LSF-240
94 1/2"
43
ST-250
LSF-240
94 1/2"
43
ST-300
LSF-240
94 1/2"
43
ST-350
LSF-240
94 1/2"
43
ST-400
LSF-300
118 3/8"
43
ST-500
LSF-300
118 3/8"
43
ST-600
LSF-340
133 7/8"
43
ST-700
LSF-340
133 7/8"
43
ST-800
LSF-360
141 3/4"
43
ST-1000
LSF-360
141 3/4"
43
ST-1250
LSF-360
141 3/4"
43
ST-1500
LSF-360
141 3/4"
43
*Fan Blade Reference number is the “LSF-XXX” markings found on the blades/hub.
