AMD ATHLON 8

72 Pin Descriptions Chapter 11
AMD Athlon™ XP Processor Model 8 Data Sheet 25175H—March 2003
Preliminary Information
AH16VSS ---
AH18
V
CC_CORE
---
AH20VSS ---
AH22
V
CC_CORE
---
AH24VSS ---
AH26
V
CC_CORE
---
AH28VSS ---
AH30 FSB_Sense[1] page 77 - O G
AH32VSS ---
AH34VSS ---
AH36VSS ---
AJ1 IGNNE# page 77 P I -
AJ3 INIT# page 77 P I -
AJ5
V
CC_CORE
---
AJ7 NC Pin page 78 - - -
AJ9 NC Pin page 78 - - -
AJ11 NC Pin page 78 - - -
AJ13 Analog page 74 - - -
AJ15 NC Pin page 78 - - -
AJ17 NC Pin page 78 - - -
AJ19 NC Pin page 78 - - -
AJ21 CLKFWDRST page 74 P I P
AJ23 VCCA page 79 - - -
AJ25 PLLBYPASS# page 78 P I -
AJ27 NC Pin page 78 - - -
AJ29 SADDIN[0]# page 79 P I -
AJ31 SFILLVALID# P I G
AJ33 SADDINCLK# P I G
AJ35 SADDIN[6]# P I P
AJ37 SADDIN[3]# P I G
Table 25. Cross-Reference by Pin Location
Pin Name Description L P R
AK2 VSS - - -
AK4 VSS - - -
AK6 CPU_PRESENCE# page 75 - - -
AK8 NC Pin page 78 - - -
AK10
V
CC_CORE
---
AK12 VSS - - -
AK14
V
CC_CORE
---
AK16 VSS - - -
AK18
V
CC_CORE
---
AK20 VSS - - -
AK22
V
CC_CORE
---
AK24 VSS - - -
AK26
V
CC_CORE
---
AK28 VSS - - -
AK30
V
CC_CORE
---
AK32 VSS - - -
AK34
V
CC_CORE
---
AK36
V
CC_CORE
---
AL1 INTR page 77 P I -
AL3 FLUSH# page 77 P I -
AL5
V
CC_CORE
---
AL7 NC Pin page 78 - - -
AL9 NC Pin page 78 - - -
AL11 NC Pin page 78 - - -
AL13 PLLMON2 page 78 O O -
AL15 PLLBYPASSCLK# page 78 P I -
AL17 CLKIN# page 74 P I P
AL19 RSTCLK# page 74 P I P
AL21 K7CLKOUT page 78 P O -
AL23 CONNECT page 75 P I P
Table 25. Cross-Reference by Pin Location
Pin Name Description L P R
(continued)
