Chapter 11 Pin Descriptions 73
25175H—March 2003 AMD Athlon™ XP Processor Model 8 Data Sheet
Preliminary Information
AL25 NC Pin page 78 - - -
AL27 NC Pin page 78 - - -
AL29 SADDIN[1]# page 79 P I -
AL31 SDATAOUTVALID# P O P
AL33 SADDIN[8]# P I P
AL35 SADDIN[4]# P I G
AL37 SADDIN[10]# P I G
AM2
V
CC_CORE
---
AM4VSS ---
AM6VSS ---
AM8 NC Pin page 78 - - -
AM10
V
CC_CORE
---
AM12VSS ---
AM14
V
CC_CORE
---
AM16VSS ---
AM18
V
CC_CORE
---
AM20VSS ---
AM22
V
CC_CORE
---
AM24VSS ---
AM26
V
CC_CORE
---
AM28VSS ---
AM30
V
CC_CORE
---
AM32VSS ---
AM34
V
CC_CORE
---
AM36VSS ---
AN1 No Pin page 78 - - -
AN3 NMI P I -
AN5 SMI# P I -
AN7 NC Pin page 78 - - -
AN9 NC Pin page 78 - - -
Table 25. Cross-Reference by Pin Location
Pin Name Description L P R
AN11 NC Pin page 78 - - -
AN13 PLLMON1 page 78 O B -
AN15 PLLBYPASSCLK page 78 P I -
AN17 CLKIN page 74 P I P
AN19 RSTCLK page 74 P I P
AN21 K7CLKOUT# page 78 P O -
AN23 PROCRDY P O P
AN25 NC Pin page 78 - - -
AN27 NC Pin page 78 - - -
AN29 SADDIN[12]# P I G
AN31 SADDIN[14]# P I G
AN33 SDATAINVALID# P I P
AN35 SADDIN[13]# P I G
AN37 SADDIN[9]# P I G
Table 25. Cross-Reference by Pin Location
Pin Name Description L P R
