AMD Radeon R7 260X User Manual

3.2 Display Configurations
The following table lists options for attaching displays that are indirectly supported by
the connections on your graphics card.
For best graphics performance and quality, always use native connections, when
available.
Note: : Adapters not provided with your graphics cards can be purchased through
your local AMD reseller or your favorite online retailer.
Table 3–1 Display Configurations
Display Configuration Connection Options
CRT (VGA) display
•
DVI connection and DVI-to-VGA adapter
•
DisplayPort connection with DisplayPort-to-VGA adapter
HDMI HDTV
•
DVI connection with DVI-to-HDMI adapter
•
DisplayPort connection with DisplayPort-to-HDMI adapter
If your graphics card includes a DisplayPort or Mini DisplayPort connection, you can
the following types of DisplayPort-compliant adapters/dongles with your graphics
card:
•
Adapters—Uses DisplayPort signals to transmit audio and video information
between variants of the same connection type (for example, Mini DisplayPort to
standard DisplayPort).
•
Active dongles—Allows connection from a DisplayPort connection to a non-
DisplayPort display using DisplayPort signals.
•
Passive dongles—Allows connection from a DisplayPort connection to a non-
DisplayPort display using non-DisplayPort signals.
The type of adapter/dongle used determines the number of displays that can be
supported by your graphics card. In general, more displays can be supported with
DisplayPort adapters and active dongles than with passive ones.
Note: A list of compatible adapters/dongles for your graphics card can be found at:
http://support.amd.com/us/eyefinity/Pages/eyefinity-dongles.aspx.
3.2.1 Multiple Displays
Your AMD Radeon™ R7 260X graphics card provides display functionality for up to
five displays using any combination of the following:
•
Any number of DisplayPort connections.
You can connect more than one display to a DisplayPort connection using a daisy
chain configuration or a hub (multi-display support is made possible through
the DisplayPort v1.2 standard).
•
Two connections between the dual-link DVI and HDMI connections.
Note: Display functionality for up to six displays may be possible through custom
display output configuration on partner boards.
8 Display Configuration
AMD Radeon™ R7 260X Graphics © 2014 Advanced Micro Devices, Inc.

AMD Radeon R7 260X Specifications

General

GPU Architecture	GCN 1.1
GPU	Bonaire
Stream Processors	896
Core Clock	1100 MHz
Memory Size	2 GB
Memory Type	GDDR5
Memory Bus	128-bit
Memory Clock	1625 MHz
Memory Bandwidth	104 GB/s
Compute Units	14
Texture Units	56
ROPs	16
TDP	115 W
Shader Model	5.0
Process Size	28 nm
Transistors	2.08 billion
Die Size	160 mm²
Power Connectors	1x 6-pin
Outputs	HDMI, DisplayPort
OpenCL	OpenCL 1.2
OpenGL Support	OpenGL 4.3
