4. Choose a refresh rate from the drop-down list.
Caution:
Choosing a refresh rate unsupported by the display may damage it. Consult
the display’s documentation if necessary.
5. Click OK.
Once you have configured the main display you can configure any other displays
that are connected.
6. To configure another display, do the following:
a. Right-click on the desktop and, in the shortcut that appears, click
Properties.
Note: The Control Center software application can also enable and
configure multiple monitors.
b. To access the basic multi-monitor configuration settings, click the
Settings tab.
c. Select the monitor icon identified by the number 2.
Note: When using multiple monitors with the graphics card, one monitor
will always be the primary display, additional monitors will be designated
as secondary.
d. Click Extend my Windows desktop onto this monitor.
e. Set the Screen Resolution and Color Quality as appropriate for the second
monitor.
f. Click OK.
10 Display Configuration
AMD Radeon™ R7 260X Graphics © 2014 Advanced Micro Devices, Inc.

AMD Radeon R7 260X Specifications

General

GPU Architecture	GCN 1.1
GPU	Bonaire
Stream Processors	896
Core Clock	1100 MHz
Memory Size	2 GB
Memory Type	GDDR5
Memory Bus	128-bit
Memory Clock	1625 MHz
Memory Bandwidth	104 GB/s
Compute Units	14
Texture Units	56
ROPs	16
TDP	115 W
Shader Model	5.0
Process Size	28 nm
Transistors	2.08 billion
Die Size	160 mm²
Power Connectors	1x 6-pin
Outputs	HDMI, DisplayPort
OpenCL	OpenCL 1.2
OpenGL Support	OpenGL 4.3
