Caution:
Static e–ect”icity can se”ious–y da—age co—pute” co—ponents. Discha”ge
you” body's static e–ect”icity by touching the powe” supp–y o” the —eta–
su”face of the co—pute” chassis befo”e you touch any co—ponents inside the
co—pute”'s case to avoid da—aging the—.
4. Unsc”ew o” unfasten and ”e—ove any existing g”aphics ca”d f”o— the co—pute”,
if necessa”y.
5. Locate the app”op”iate bus s–ot and, if necessa”y, ”e—ove the co””esponding
—eta– backp–ate cove”(s). Make su”e a–– inte”na– cab–es a”e c–ea” of the s–ot.
Note: If you cannot find a bus s–ot to —atch the ca”d, you need a g”aphics ca”d
with the co””ect bus to —atch the —othe”boa”d.
6. A–ign the g”aphics ca”d with the s–ot and p”ess it in fi”—–y unti– the ca”d is fu––y
seated.
7. If you” ca”d ”e“ui”es supp–e—enta”y powe” and —ust be connected di”ect–y to
the powe” supp–y, –ocate the app”op”iate powe” connecto” cab–e(s) f”o— the
powe” supp–y and connect it (o” the—) to the g”aphics ca”d's supp–e—enta”y
powe” connecto”(s).
Note: If app–icab–e, befo”e insta––ing a ca”d that ”e“ui”es a supp–e—enta”y
powe” connection, —ake su”e you” existing powe” supp–y has such a
connection avai–ab–e.
Tip: The –ocation of powe” connections —ay va”y between —ode–s. They can
be –ocated on eithe” the side o” back of the ca”d.
Figure 2–1 Possible Power Connection Locations on the Graphics Card
1 Powe” supp–y
2 G”aphics ca”d
8. Fasten the g”aphics ca”d secu”e–y to the back pane–.
9. Make su”e no inte”na– cab–es a”e inte”fe”ing with co—ponents inside the
co—pute” (fo” exa—p–e, a coo–ing fan), and then ”ep–ace the co—pute” cove”.
4Hardware and Software Installation
AMD Radeon R9 290 Series ©2013Advanced Micro Devices, Inc.
