AMD VIA K8M800 - Item Checklist; Layout Diagram & Jumper Setting

4
1-3 Item Checklist
5
VIA K8M800 Chipset motherboard
5
Cable for IDE
5
CD for motherboard utilities
5
Cable for Serial ATA IDE Port
5
VIA K8M800 Chipset motherboard User’s Manual
1-4 Layout Diagram & Jumper Setting
Front Panel Audio
CD IN
PC99 Back Panel
PS2 KB/Mouse Port
K/B Power
ON Jumper (JP1)
USB Port
(USB2, USB3)
PCI Slot
6-CH AC’97
Audio Codec
4MBit Flash ROM BIOS
SFAN1
ATA 133 IDE
Connector (IDE1, IDE2)
Clear CMOS (JBAT)
VIA VT8237R Plus Chip
Speaker / Power LED
Connector
VIA K8M800
Chi
p
set
CPU Socket
DDRII Socket X2
USB Port/
LAN Connector
USB Port
Audio Connector
Front Panel Connector
VIA VT6103
LAN PHY
USB Power
On Jumper (JP2)
ATX Powe
r
Connector
Serial-ATA
Connector (SATA1, 2)
CPU FAN
ATX 12V Connecto
r
SFAN2
Floppy
Connector
AGP 8X Slot
