HDMI Clocking
HDMI Source Clock
The VEK280 evaluation board includes a Renesas RC21008A (U299). This chip is
used to source the 400 MHz FRL/DRU clock used as the reference for driving the
Versal device (U1) logic and related circuitry for HDMI.
