Callout No.Ref. Des. Feature Notes Schematic Page
49 J349 System controller
SGMII Ethernet,
RJ45 w/magnetics
Halo HFJ11-1G01E-L12RL
RJ-45 Gigabit connector
84
50 DS34 System controller
done LED (active-
High)
Lumex SML-LX0603GW-TR
LED green
77
1. The VEK280 evaluation board includes a heatsink with a thermal resistance
of 0.46°C/W.
Default Jumper and Switch Settings
The following figure shows the VEK280 board jumper header and switch locations.
Each numbered component shown in the figure is keyed to the applicable table in
this section. Both tables reference the respective schematic page numbers.
Figure: Board Jumper Header and Switch Locations
