Callout No.Ref. Des. Feature Notes Schematic Page
41 DS3,
DS4,
DS5,
DS6
User LEDS Lumex SML-LX0603GW-TR
LED green
48
42 J405 IEEE-1588 eCPRI
CLK in SMA
Rosenberger 32K10K-
400L5
Conn. rcpt. SMA vert. 50R
12.4 GHz
92
43 J331 IEEE-1588 eCPRI
CLK out SMA
Rosenberger 32K10K-
400L5
Conn. rcpt. SMA vert. 50R
12.4 GHz
92
44 U125 XCZU4EG system
controller
AMD XCZU4EG-2SFVC784E
AMD Zynq™ UltraScale+™
MPSoC
73-83
45 U301 SYSCTLR
clock156.25 MHz
HSDP REFCLK
CTS 626L15625I3T
Osc 156.25 MHz 3.3V 25
PPM LVDS with OE
89
46 U302 SYSCTLR clock
33.33 MHz
REFCLK
Renesas
XUJ716033.333333I
Osc 33.333333 MHz 1.8V
25 PPM LVCMOS with OE
89
47 U304 SYSCTLR clock 26
MHz USB REFCLK
Raltron XCO583IV11-
26.000
Osc 26 MHz 3.3V 30 PPM
LVDS with OE
89
48 U132 System controller
LPDDR4 16 GBIT
comp. memory
Micron
MT53E512M32D1ZW-046
WT:D
IC SDRAM LPDDR4 16 Gb
512Mx32 2133 MHz
86
