Callout No.Ref. Des. Feature Notes Schematic Page
31 J325 PMBus 3-pin
header
Sullins PBC03SAAN
Conn. hdr. vert. 3 pos. 1x3
2.54 mm
55
32 Various Power good LEDs
(see Power and
Status LEDs for
more details)
Various; see the Bill of
Materials
72
33 J16 Power connector,
2x3, for AC-DC
power adapter
Molex 0039301060
Conn. ddr. RA 6 pos. 2x3
4.2 mm
50
34 JP1,
JP2
Power connector,
2x4, for ATX PCIe
power
Astron 6652208-T0003T-H
Conn. hdr. male RA 8 pos.
2x4 4.2 mm
50
35 J233 Fan header (keyed
4-pin)
Molex 0470533000
Keyed fan header 4 pos.
0.100" vert.
50
36 U299 MGT and system
clock generators
Renesas
RC21008A065GND#BB0
93
37 J374 RC21008A_GTCLK
header
Molex 0878321820 93
38 U297 Adaptive SoC U1
OSPI
Micron
MT35XU02GCBA1G12-0SIT
IC flash Xccela 2 Gb SPI
200 MHz 1.8V
28
39 DS1 Done LED (Active-
High-Z and pulled
High)
Lumex SML-LX0603GW-TR
LED green
12
40 DS2 Error out LED
(Active-High-Z and
pulled High)
Lumex SML-LX0603IW-TR
LED red
12
