Table: User I/O
Net Name Ref. Designator Schematic Pages
GPIO_PB0 SW4 4, 48
GPIO_PB1 SW5 4, 48
GPIO_DIP_0 SW6 4, 48
GPIO_DIP_1 SW6 4, 48
GPIO_DIP_2 SW6 4, 48
GPIO_DIP_3 SW6 4, 48
GPIO_LED0 DS6 3, 48
GPIO_LED1 DS5 3, 48
GPIO_LED2 DS4 3, 48
GPIO_LED3 DS3 3, 48
Power and Status LEDs
[Figure 1, callout 32]
The following figure shows the power and status LEDs.
Figure: Power and Status LEDs
