INSTALLING THE LAMP
CAUTION!
DO NOT INSTALL LAMP UNLESS THE POWER HAS BEEN TURNED OFF AT THE
POWER SOURCE.
IMPROPER LAMP INSTALLATION WILL DAMAGE THE LAMP ENDS AND SOCKET.
DO NOT HANDLE THE GLASS QUARTZ SURFACE OF THE LAMP.
Handle the lamp only with cotton gloves or a clean cloth. If the lamp surface is
accidentally touched, wash the lamp with isopropyl alcohol to remove all traces
of fingerprints, grease or oil. (Be sure the lamp is dry before installation.) Failure
to clean the lamp will result in premature failure.
IMPORTANT:
MODELS 335, 340, 350, 355 & 370 USE ONLY AMERGRAPH LAMP P/N 10266.
THE USE OF SUBSTITUTE LAMPS will result in premature
failure and possible damage to the electrical circuitry and
WILL VOID ALL WARRANTIES!
For MODELS 335 & 340, access to the lamp holder is through the top of the unit. Open
the blanket frame, followed by the glass frame. Reach down from above.
For MODELS 350, 355, & 370, access to the lamp holder is from the bottom front
drawer, which is secured by two Allen cap screws requiring a 3/16” Allen wrench. Loosen
the screws, but do not remove them. Then pull the drawer open to expose the lamp holder.
1. Carefully slide one end of the lamp into one of the lamp clips.
2. Then gently insert, without “snapping” or forcing, the other end of the lamp into
the other lamp clip.
3. Without handling the glass quartz surface, position the lamp with the tip of the
lamp pointing up.
