SENSORRAIL IIIE 8200-0593-03, REV. A
SERVICE GUIDE
10 of 34
ATMEGA 128 block diagram
Vision area (for surveillance), dead zones (for stopping), and maintenance areas (for servicing)
Vision Area
Vision Area + Two 1.5m (4.9ft) Dead Zones
Vision Area + Two 1.5m (5ft) Dead Zones +Two 30cm (1ft) Light Reduction Sections = Total Length of Rail
Total Length of Rail + Two 0.6m (2ft) Maintenance Areas
Rail
