SENSORRAIL IIIE 8200-0593-03, REV. A

SERVICE GUIDE

7 of 34

CPU Board Layout

RF 2.4GHz Emitter

ATMEGA 128 µP X-

Electronic Brake Devices

BNC

RF 2.4GHz connector

JTAG Connector

B Sensor

Main Connector

Power Connector

DIP Switches
