SENSORRAIL IIIE ADRL3TRK SERIES 8200-0593-02, REV. A
INSTALLATION GUIDE
13 of 34
10. Attach Light Reducing
Sections
Light reducing sections are not used by the camera
trolley, but rather to reduce light that can enter the
cowling from the ends of the rail. A light reducing
section attaches to each end of the rail.
Tools, Equipment, and Parts Required for
this Operation
Proper lift equipment (scissor lift with extended
work platform is recommended)
30cm (11.8in) light reducing section with
top hat (2).
Procedure
A. Join a light reducing section to the start of
the rail.
1. To allow for installation of the end covers,
the top hat must be shifted so it lies slightly
over the first rail section. To facilitate this—in
the top jointing plates—insert the small Allen
screws into the large Allen screw holes that
lie over the light reducing section and place
the two large Allen screws aside for later
use.
2. Uniformly butt a light reducing section to the
rail by sliding the mating groove of that
section over the protruding jointing plate. No
space should be between the two sections.
3. Center the jointing plates over the joint and
hand-tighten the outside screws of all plates.
4. Secure the top hat to the light reducing
section by inserting screws and nuts through
holes in the top hat flange that faces the end
of the rail, and use the two large Allen
screws to secure the other end of the top hat
to the two top jointing plates.
5. Tuck any excess tape into the space within
the light reducing section at the start end of
the rail.
B. Repeat step A to attach the other light
reducing section to the end of the rail.
11. Clean the Rail
The rail is sensitive to fingerprints. To clean the
rail, use a tissue soaked with window glass cleaner
or use a window glass cleaning pad.
12. Check Electrical Connections
Ensure electrical connections from the PowerRail
module to the track and antenna are correct. Verify
that the copper tracks do not touch each other at
the ends of the rail or touch the structure.
