Specifications
(Excluding Dome Camera)
Operational
Maximum rail length.................................. 100m (328.1ft)
Video travel distance .................................. 97m (318.3ft)
Travel speed:
Nominal....................................................3m/s (9.8ft/s)
Preset.....................................................6m/s (19.6ft/s)
Preset positioning................................0.3m/s (0.98ft/s)
Patrol mode...........................................1.5m/s (4.9ft/s)
Initialization mode ....................................1m/s (3.3ft/s)
Cowling density............. f0.7–f0.95 (15–16% penetration)
Camera....................... See manual supplied with camera
Controller ................. See manual supplied with controller
Electrical
Power requirements:
Supply voltage (auto switched) ... 90–240Vac, 50/60Hz
Current (120Vac)....................... 5A typical (10A surge)
Current (240Vac)...................... 2.5A typical (5A surge)
RF link transmitter:
RF frequency range .................... 2.4–2.483GHz (PAL)
over 5 channels
Transmission power ..................................10mW EIRP
Video input ............................... Composite PAL 1V p-p
Video bandwidth........................................30Hz–5MHz
Power supply............................................. 12.8–15Vdc
Nominal current................................................. 240mA
RF link receiver:
RF frequency range .................... 2.4–2.483GHz (PAL)
over 5 channels
Video output............................. Composite PAL 1V p-p
Sensitivity........................................ –86dBm (21dBµV)
Power supply.................................................. 8–10Vdc
Nominal current................................................. 250mA
Trolley motor:
Nominal voltage ................................................. 24Vdc
Nominal speed ............................... 6700rpm clockwise
Nominal torque............................................ 1250m Nm
Nominal current (w/o load) ................................ 0.120A
Speed constant ............................................. 287rpm/V
Cabling
Power ........................................................IEC connector
Video* .....................................................Coaxial RG59/U
RS-422 data ..................Cat. 5. 1 x twisted pair, shielded
* KX-6 for <300m from PowerRail to matrix switcher,
KX-8 for <800m from PowerRail to matrix switcher.
Environmental
Operating temperature .................................. –10 to 50°C
Storage temperature ..................................... –20 to 65°C
Rate of change per hour (max.) .................10°C per hour
Altitude (max.) ............................. 3660m above sea level
Relative humidity......................0 to 95% non-condensing
Mechanical
Single rail section:
Length ........................................................2.5m (8.2ft)
Width ..................................................... 188mm (7.4in)
Height (w/o cowling) .............................. 141mm (5.6in)
Height (w/cowling) .................................. 255mm (10in)
Weight ......................................6.7kg/m (14.7 lbs/3.3ft)
Material.......................................... Extruded aluminum
Cowling material....................... 175 micron Polyester film
Trolley (w/dome camera)
Dimensions (H x W x L).................225 x 131 x 400mm
Weight ....................................................... 5kg (11 lbs)
