MEGAPOWER 48 / ADTTE 8200-0170-05, REV. A
OPERATION AND PROGRAMMING REFERENCE GUIDE 2 of 43
Contents
About this Guide.................................................... 2
About the MegaPower 48 Matrix
Switcher/Controller System................................... 3
About the ADTTE Keyboard Controller ................. 3
Identifying the ADTTE Operating Mode ................ 6
General User Tasks .............................................. 7
Working in Keyboard Lock Mode .......................... 7
Working in Program Mode................................... 14
Changing ADTTE Keyboard Settings.................. 20
Working in Menu Mode ....................................... 22
Changing System Settings.................................. 23
Changing Monitor Settings.................................. 27
Changing Camera Settings ................................. 28
Configuring User or Keyboard Settings............... 30
Configuring Switching Settings ........................... 33
System Partitioning ............................................. 37
Configuring Alarms.............................................. 39
Declarations ........................................................ 43
About this Guide
This operation and reference guide explains tasks
you can perform using the ADTTE keyboard with
the MegaPower 48 (MP48) Matrix Switcher. It
supplements material found in the following
documents:
• ADTTE Enhanced Touch Tracker Operator’s
Manual, 8000-2675-02
• MegaPower 48 (MP48) Matrix Switcher/
Controller Programming & Operation Manual,
8000-1804-51
If you need assistance...
Contact your Sales Representative.
