American Standard Selectronic 606B.X10 User Manual

2
Thank you for selecting American-Standard...the benchmark of ne quality for over 100 years. To ensure that your
installation proceeds smoothly--please read these instructions carefully before you begin.
Remove the Flush Valve items from the carton. The illustration below shows all items after they have been
removed from the carton. Some items may be packaged partially assembled to other items.
UNPACKING
All American Standard Products Are Water Tested At Our Factory.
Some Residual Water May Remain In The Valve During Shipping.
1. Installation Instructions
2. Flush Valve Body Assembly
3. Cover Plate with Sensor
4. Wall Box
5. Sweat Adapter
6. Stop Valve
7. Manual Override Hoses
8a. Vacuum Breaker Flush Connection
(Top Spud)
8b. Vacuum Breaker Flush Connection
(Back Spud)
9. Safety Chain
8a 8b
606X.4XX 606X.5XX
VACUUM BREAKER FLUSH CONNECTIONS
3
4
1
9
6
5
2
7
LARGE PLATE CONCEALED TOILET FLUSH VALVES
DO NOT REMOVE PROTECTIVE
FILM FROM SENSOR
EYE UNTIL INSTALLATION
IS COMPLETE.
Installation Instructions
Certified to comply with ASME A112.19.2M
© 2014 AS America, Inc.
SELECTRONIC™
PROXIMITY CONCEALED
URINAL FLUSH VALVE
1.0, 0.5 & 0.125 GPF
Concealed Flushometer
for 3/4" Top or Back Spud Urinals
CLOG RESISTANT
• Self-cleaning piston valve prevents clogging and reduces maintenance.
ONE SENSOR FITS ALL
• Only 1 sensor for entire Selectronic™ line of faucets, urinals, and
flush valves.
• Range can be adjusted manually or with optional remote control.
• Sensor Features Low Battery Indicator.
MODEL NUMBERS
1.0, 0.5 & 0.125 GPF
CAUTION: Use only American Standard
supplied cable sets. Using non-AS supplied
cables, or cutting, splicing or modifying any
components will void the warranty.
6061.X10
6062.X10
6063.410
6063.511
6061.X05
6062.X05
6063.405
6063.515
6061.X01
6062.X01
6063.X03
(In Toronto Area only: 1-905-3061093)
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Selectronic
®
Products visit our website at: www.americanstandard-us.com
or e-mail us at: sensor@americanstandard.com
For Parts, Service, Warranty or other Assistance,
please call
(855) 752-9259 (In Canada: 1-800-387-0369)
(In Toronto Area only: 1-905-3061093)(In Toronto Area only: 1-905-3061093)
NOTE TO INSTALLER: Please give this manual to the customer after installation.
To learn more about American Standard Selectronic
®
Products visit our website at: www.americanstandard-us.com
or e-mail us at: CRTTEAM@americanstandard.com
For Parts, Service, Warranty or other Assistance,
please call (855) 752-9259 (In Canada: 1-800-387-0369)
(In Toronto Area only: 1-905-3061093)
POWER KITS — SOLD SEPARATELY
Plug-In AC
Power Kit
Hard-Wired AC
Power Kit
Multi-AC
Power Kit
PWRX
Power Kit
PK00.PACPK00.WRK
PK00.HAC
PK00.MAC
CR-P2 Battery
Power Kit
M965643 Rev. 1.6 (11/16)
