Section 1. GENERAL DESCRIPTION
The AM100 is a security system control that supports up to 38 zones, using basic hard-wired,
wired expansion, and/or wireless zones, plus 3 keypad activated zones.
Basic Hardwired Zones
Provides 8 basic hardwired zones having the following characteristics:
• EOLR supervision supporting N.O. or N.C. sensors
• Programmable response time (10, 350, or 700 milliseconds)
• Up to sixteen 2-wire smoke detectors on zone 1
• 4-wire smoke or heat detectors on zones 2 through 7 (as many as can be
powered from AUX power on the control)
• Up to fifty 2-wire latching type glassbreak detectors on zone 8 with
auto reset
Optional Expansion Zones (up to 30 total, wired and wireless)
Wired Expansion:
Supports up to 8 additional wired zones using a 4219 expansion module or
4229 expansion/relay module. These zones have the following
characteristics:
• EOLR supervision supporting N.O. or N.C. sensors
• 300–500 msec normal response with an option for fast (10–15 msec)
response on loop A (first expansion zone)
Wireless Expansion:
Supports up to 30 wireless zones (less if using wired expansion zones).
• Requires the use of a 5881(5882 in Canada) type RF Receiver, as
indicated below
Receiver Model No. of Zones
5881L/5882L Up to 8
5881M/5882M Up to 16
5881H/5882H Up to 30
• Requires the use of 5800 series wireless transmitters
Remote Keypads
Up to 8 of any of the following keypads may be used in the installation:
Fixed-Word Keypad: AM6128
Alpha Keypad: AM6139 (2-line alphanumeric display)
For programming from a keypad, a AM6139 2-line Alpha keypad must be
connected, but need not remain in the system after programming has been
completed.
