Page 13<&(%$*4.8"4,7%H'*#$"&8#I%/7*,#*%4,77%JKLLLKLMMKNOPO1Item 64017
?@<6AQRS6;@ACRED@CEA6E@ET6 ?6AFS
;*#"#$,84*%D*,#'(*5*8$
Measure circuit resistance up to 60M Ohms�
U@;ECEV` To prevent electric shock, turn
off all power and fully discharge capacitors
on the circuit under test before measuring�
E&$*- When measuring Ohms,
start with the lowest range if the
resistance is unknown�
1� Plug black test lead into TRD Jack�
Plug red test lead into CESFA Jack�
2� Turn the Rotary Switch to the
Ω position�
3� Carefully touch exposed
conductors with tips of probes�
4� Read measured resistance
on the Display�
5� When testing is complete, turn
Rotary Switch to R<<, remove
Test Leads and store with Meter�
E&$*- Sometimes the resistor value and
measured resistance differ� This is due
to the Meter’s output test current going
through all possible paths between leads�
E&$*- For resistance measurements
above 1MΩ, allow a few seconds
to get a steady reading�
E&$*- When leads are disconnected
or measurement is out of
range, RG is displayed�
T&8$"8'"$>%D*,#'(*5*8$
Test continuity between two
points of a circuit�
U@;ECEV` To prevent electric shock, turn
off all power and fully discharge capacitors
on the circuit under test before measuring�
1� Plug black test lead into TRD Jack�
Plug red test lead into CESFA Jack�
2� Turn the Rotary Switch to
the Ω position�
3� Press <FET until is displayed�
4� Connect the test leads across
the circuit to be measured�
5� Read measured resistance on the
Display� If the measured resistance
is less than 50Ω, Meter will beep.
6� When testing is complete, turn
Rotary Switch to R<<, remove
Test Leads and store with Meter�
E&$*- If Test Leads are open or
the resistance of the circuit is
over 600Ω, RG is displayed�
