10.0 Standard insertion tubes
Caution…
Use of other insertion tubes may reduce performance of the
calibrator. To get the best results out of your calibrator, the
insertion tube dimensions, tolerance and material are
critical. We highly advise using the JOFRA insertion tubes,
as they guarantee trouble free operation.
PARTS NO. FOR STANDARD INSERTION TUBES WITH HOLES
FOR 4 MM/1/4” REF. SENSORS AND DLC SENSOR - UNDRILLED
Sensor
size
RTC-156
/
157
A/B/C
(Aluminium
tubes)
RTC-159
A/B/C
(Aluminium
tubes)
RTC-158
A/B/C
(Aluminium
tubes)
RTC-250
A/B/C
(Aluminium
tubes)
RTC-700
A/B/C
(Alu. Bronze
tubes)
Undrilled 127299 128453 124899 127758 127197
Undrilled with
DLC hole
127300 128454 127829 127834 127198
Undrilled with
DLC and ref.
holes
127301 128455 127831 127835 127199
PARTS NO. FOR STANDARD INSERTION TUBES –
MULTI-HOLE - METRIC
Insert type
RTC-156/157 A/B/C
(Aluminium tubes)
RTC-159 A/B/C
(Aluminium tubes)
RTC-700 A/B/C
(Alu. Bronze tubes)
Type M01 127329 128456 127200
Type M02 127330 128457 127201
Type M03 127331 128458 127202
Type M04 127332 128459 127203
Type M07 127241 128462 127244
Type M08 127242 128463 127245
Type M09 127243 128464 127246
Set of 4 pcs. Inserts,
3mm to 13mm.
127326 128466 127252
