Fig. 5
Caution…
 The tip of the sensor should rest at the bottom of the
sensor basket for optimum results.
 Be careful not to submerge the handle or wire inlet of the
sensor-under-test in the fluid, as this might damage the
sensor.
 The calibrator is now ready for use.
Support rod set
Sensor under test
