Type T Pump Operation Manual
X
Figure 1.4 • Hydraulic Hand Pump Type T Assembly Parts List
Item
Number
Part
Number
Description
Units Per
Assembly
1 – Type T Pump Assy 1
2 01-90007 Screw, Drip Pan Attaching 4
3 T-167 Washer, Drip Pan Attaching 4
4 T-118 Drip Pan 1
5 T-149 Manifold Assembly (see page 32) 1
6 T-328 Cap, Reservoir 1
7 10-90010 O-ring, Reservoir Tube (T-156) 2
8 T-131 Tube, Reservoir 1
9 T-130 Stud, Reservoir 1
10 T-140 Tube, Inlet 1
11 12-90152 Fitting, Inlet Tube 1
12 T-165 Handle, Pump 1
13 T-145 Pin, Piston 1
14 T-161 Shoe, Piston Pin 1
15 T-160 Screw, Piston Pin 3
16 T-142 Pin, Clevis 2
17 T-143 Clevis 1
18 T-144 Hair Pin, Cotter 2
19 T-108 Plug, Cylinder Retaining 1
20 10-90019 Back-up Ring, Piston (T-158) 1
21 10-90006 O-ring (T-154) 1
22 T-106 Piston 1
23 10-90005 O-ring (T-151) 2
24 10-90018 Back-up Ring, Piston (T-159) 1
25 10-90020 Back-up Ring, Cylinder (T-112) 2
26 10-90013 O-ring (T-153) 3
27 T-236 Cylinder, Pump 1
28 10-90012 O-ring, Cylinder (T-164) 1
29 T-595 Liner, Body Plate 1
30 T-408 Plate, Body 1
31 01-90004 Screw, Body Attaching 3
32 IGT-302 Plug and Spacer, Fill and Vent Relief Assy 1
Item
Number
Part
Number
Description
Units Per
Assembly
33 10-90001 O-ring (T-152) 3
34 T-194 Poppet, Valve 1
35 CV-1-5 Spring, Check Valve 3
36 T-127 Spacer, Check Valve 2
37 10-90027 O-ring (T-154) 2
38 T-117 Plug, Pump Body 2
39 10-90002 O-ring (T-175) 1
40 T-111 Seat, Relief Valve 1
41 T-109 Body, Relief Valve 1
42 10-110 Stem, Relief Valve 1
43 T-773 Handle, Relief Valve 1
44 T-147 Poppet, High Pressure Valve 2
45 T-107 Guide Rod 1
46 T-141 Plug, Retaining 1
47 10-90009 O-ring (T-136) 1
48 T-103 Plug 1
49 T-166 Screw 1
50 T-116 Spring, Valve Rod 1
51 T-133 Detent Pin, Valve Rod 1
52 10-90004 O-ring 1
53 T-115 Valve Rod 1
54 T-120 Body, Pump 1
