Operation and Maintenance
GENERATING PRESSURE
Note: It may be necessary to prime the pump, particularly if the pump has been inactive for an extended period of time. Refer to Priming on page 10
for instructions on priming the pump.
1
Check that the vent ll plug is fully open by turning it counter-clockwise.
2 Open the vent valve.
Open the vent plug… then open the vent valve.
3 Set the valve rod selector to control your desired uid output volume.
!
CAUTION: Only move the valve rod selector while the pump handle is stationary, in the up position.
Note: With the valve rod in the “out” position, uid ow will be at maximum and the maximum achievable pressure will be 1000 psi. To exceed 1000 psi,
push the valve rod in.
Low Pressure/
High Volume
High Pressure/
Low Volume
