MODEL 227
OPERATION MANUAL
Doc # 740063 Rev E
SECTION II - SPECIFICATION
2.1 PHYSICAL CONSTRUCTION
Cabinet material - aluminum
Height = 13.9 inch (353.1mm) cover closed
12.3 inch (312.4 mm) cover removed
Width = 22.75 inch (577.9 mm)
Depth = 19.25 inch (489.0 mm)
Weight = 91 lbs (41.3 kg)
2.2 PROGRAMMABLE FUNCTIONS
PREPURGE TIME = 010 - 999 seconds
POSTPURGE TIME = 000 - 999 seconds
UPSLOPE TIME = 00.0 - 99.9 seconds
DOWNSLOPE TIME = 00.0 - 99.9 seconds
ROTATION START DELAY = 00.0 - 99.9 seconds
ROTATION MODE SETTINGS = CONT - STEP - OFF
ROTATION DIRECTION = CW - CCW
PRIMARY ROTATION SPEED = 0.00 - 20.0 RPM
BACKGROUND ROTATION SPEED = 0.00 - 20.0 RPM
WIRE FEED START DELAY = 00.0 - 99.9 seconds
PRIMARY WIRE FEED SPEED = 000 - 200 IPM
BACKGROUND WIRE FEED SPEED = 000 - 200 IPM
WIRE FEED STOP DELAY = 00.0 - 99.9 seconds
WIRE FEED RETRACT TIME = 0.0 - 1.0 seconds
PRIMARY AVC = 5.0 - 20.0 volts
BACKGROUND AVC = 5.0 - 20.0 volts
AVC START DELAY TIME = 00.0 - 99.9 seconds
AVC STOP DELAY TIME = 00.0 - 99.9 seconds
AVC MODE SETTINGS = CONT - SAMPLE - OFF
OSCILLATION MODE = ON - OFF
TORCH OSCILLATION AMPLITUDE = Determined by Head Type
OSCILLATION IN and OUT DWELL TIMES = 0.00 - 9.99 seconds
OSCILLATION EXCURSION TIME = 0.00 - 9.99 seconds
PULSE MODE SETTINGS = ON - OFF - SYNC (to osc)
PRIMARY PULSE TIME = 0.00 - 9.99 seconds
BACKGROUND PULSE TIME = 0.00 - 9.99 seconds
LEVELS = 1 - 99
LEVEL TIME (each level) = 000 - 999 seconds*
PRIMARY CURRENT = 3 - 225 amperes*
BACKGROUND CURRENT = 3 - 225 amperes*
* = Can be in increments of 0.1
